Modular heat recovery and air purification technology for retrofitting existing gas-engine, biogas, boiler and industrial energy systems to higher efficiency.
It recovers the energy of unused flue-gas heat and extracted process air for district heating, hot water and space heating. A performance commitment that can be categorised in advance, based on on-site measurement, with measurable savings potential.
Technology overview
THE CAN™ is a modular heat recovery and air purification system that uses currently unused flue-gas heat and the energy content of warm, humid or contaminated extracted process air. The recovered energy can be fed back into district heating, domestic hot water, process water or building heating.
For gas-engine power plants in combined heat and power, and for operators of gas turbines and absorption chillers, it delivers outstanding efficiency and optimised operation. District heating, biomass and gas-boiler heat production, industrial utilities, swimming pools and spas: measurable savings potential.
Water-based air cleaning, reduced point-source emissions, measurable ESG results. The investment fits energy-performance contracts and European funding programmes (BAFA, PNRR, UFI).
Cleaning and heat extraction
Extraction
Gas or air enters at the bottom, driven by the unit's own fan.
Water-gas contact
Cold water sprayed from above: intense heat and mass transfer.
Separation
Water-soluble components, aerosols and particles pass into the scrubbing liquid, then filtration.
Heat extraction
The heat pump recovers the heat; the condenser conditions the air.
Six value propositions in one system6
- Heat recovery with heat pump
- Air cleaning, water-based filtration
- Humidity control
- Reduced point-source emissions
- Modular, cascadable installation
- Measurable savings potential
Technical range
Applications and models
CAN PR
Comfort air handling: filtration, heat recovery, humidity control. Treatment of low-temperature waste-heat air in industrial halls, with a heat pump.
textiles, paper, welding shops, plastics production, industrial ventilation, spas and swimming pools.
According to the manufacturer's source material, energy savings of 50 to 70 percent can be achieved by replacing a steam boiler. Indicative value: no independent measurement report is available yet.
CAN PR-HT
High-temperature air handling: heat recovery, filtration. Treatment of high-temperature flue gas and process waste heat.
district heating plants, biomass boilers, industrial furnaces, power plants, gas engines.
flue-gas heat recovery, capture of contaminants.
CAN PR-HT-PWR
Replacing electricity demand with heat energy. A compressor covers the heat pump's energy demand, so the system also runs off-grid.
Industrial sites far from the grid, off-grid applications, plants with high electricity demand.
Energy self-sufficiency, maximum energy efficiency built on the existing CAN PR-HT functions.
Technical parameters will be published at launch.
Modular capacity: 1,000 to 15,000 m³/h air flow per module; the 15,000 m³/h unit is 2.4 m wide and the system scales in parallel cascade up to 60,000 m³/h. The actual size is defined by air volume, temperature, contaminants and operating hours.
Fields of application
THE CAN™ offers a modular retrofit for existing, continuously operating gas-engine, biogas, boiler and industrial energy systems. For gas-engine power plants in combined heat and power and for operators of gas turbines and absorption chillers, it provides outstanding efficiency and optimised operation.
Currently unused flue-gas heat, and warm, humid or contaminated extracted process air.
Energy9
- Biogas upgrading
- CO₂ capture (CCU)
- H₂ production (electrolysis)
- Heat supply, biomass
- Heat supply, gas boiler and gas engine
- Heat supply, geothermal
- Fuel-cell cogeneration
- Compressed-air energy storage
- Combined heat and power: gas-engine plants, gas turbines, absorption chillers
Heavy industry4
- Steelworks coke ovens
- Pulp and paper (black-liquor MVR)
- Cement production
- Refineries (VGO hydrotreating)
Public services1
- Swimming pools, spas, wellness
Light manufacturing and agriculture9
- Battery manufacturing
- EV battery-swap stations
- CNC machining
- Plastics industry
- Optical fibre drawing
- Insect farms
- Textile dyeing
- Vertical farms (CEA)
- Welding and workshop industry
Transport2
- Maritime shipping
- Aircraft maintenance (MRO)
Areas with special requirements5
- 3D printing
- Data centres, liquid cooling
- Data centres, air cooling
- Food processing
- Pharmaceuticals, freeze drying
Beyond these, there are application opportunities in almost every industry.
Swimming pools, spas, wellness2
Key target area: continuous operation, high humidity and heat load, immediately measurable savings. The heat content of the warm, humid extracted air can be returned to domestic hot water and pool-water heating.
- PE structural elements: an advantage in chloramine-laden, aggressive air.
- According to the source, investment costs 20 to 30 percent lower and energy cost savings of 30 to 40 percent can be achieved (indicative value).
Cooperation and process
Forms of cooperation8
- Full-cycle service model
- Worldwide representation and distribution network development
- Energy-saving asset management
- On-site survey and measurement
- Categorised offer based on measured data
- Modular installation next to the existing technology
- Energy-performance service contract
- Partner resale and project coordination
From pre-screening to verified performance5
- Quick pre-screening: problem, air flow, potential value
- On-site measurement: mass and energy balance, sampling
- Technical and business model: equipment selection, useful heat, payback range
- Detailed design: mechanical, electrical, HVAC integration
- Commissioning and verification: before-and-after measurement, accredited report
Performance commitment
- Tied to on-site measurement
- Categorised in advance
- Accountable with measured data
Every offer is built on the site's measured data; the expected savings are defined after the survey and can be categorised and planned in advance.
Business case
Payback typically between 4 and 5 years, depending on the funding and savings schemes (energy-efficiency obligation scheme, European programmes, the value of the recovered heat).
Service cooperation: 5+ years.
Warranty: 2+3+5 years with extended warranty, continuous remote monitoring and maintenance.
The energy savings and energy cost savings figures shown are different indicators, so they cannot be compared directly or added together. The net savings expected for a given project are determined on the basis of on-site data, under comparable operating conditions, also taking into account the system's own energy consumption.
Certification and verification
MN 69267406 0001 · 2024✓Performance verified
by accredited measurements
References under real industrial conditions
Two-year test period: THE CAN™ units operated under live conditions, in test operation, at the following companies.
6 × CAN GM-PR 1 (1,000 m³/h) + 2 × CAN GM-PR 3 (3,000 m³/h), 1,000 m² welding shop
1 × CAN GM-PR-HT 1 (1,000 m³/h), emission treatment of a rubber-fired boiler, pilot project
3 × CAN GM-HP-PR 4 (4,000 m³/h)
1 × CAN GM-HP-PR 15 (15,000 m³/h), additional unit to serve a different hall use
3 × CAN GM-HP-PR 7 (7,000 m³/h)
3 × CAN GM-HP-PR 15 (15,000 m³/h), total 45,000 m³/h
| Company | Location | Installed units |
|---|---|---|
| KIS Kft. | Sajóbábony | 6 × CAN GM-PR 1 (1,000 m³/h) + 2 × CAN GM-PR 3 (3,000 m³/h), 1,000 m² welding shop |
| Reál-Fém Bt. | Nyíregyháza | 1 × CAN GM-PR-HT 1 (1,000 m³/h), emission treatment of a rubber-fired boiler, pilot project |
| MANITOX Kft. | Tiszaújváros | 3 × CAN GM-HP-PR 4 (4,000 m³/h) |
| KIS Kft. | Sajóbábony | 1 × CAN GM-HP-PR 15 (15,000 m³/h), additional unit to serve a different hall use |
| Nyitott Ajtó Baptista Misszió | Miskolc | 3 × CAN GM-HP-PR 7 (7,000 m³/h) |
| ONGROPACK Kft. | Szirmabesenyő | 3 × CAN GM-HP-PR 15 (15,000 m³/h), total 45,000 m³/h |
Beyond these, there are sales opportunities in almost every industry.
Representation
International strategic, business-development and investment representation of "THE CAN": Real Energy Group
Official representation: Real Energy Group. Representation in Hungary: Real Energy Enterprises Kft.
